C-10-24 Resin Static Mixer Nozzles for Dual Cartridge mixing nozzle for adhesive and AB glue dispensing gun
Specification
| Item | Value |
| Product Name | C-10-24 plastic static mixer nozzle |
| Brand Name | Eestron |
| Material | PP/POM |
| Application | Mixing Adhesive |
| Feature | disposable,excellent sealing |
| OEM | Allowed |
| Application Area | Construction, Concrete, Industry, Hardware |
| Processing Service | Moulding |
| Place of Origin | kunShang China |
| Packaging | Master Carton or to be customized. |
characteristic
The structure is simple and easy to install.
No moving parts during operation, low pressure drop, suitable for mixing materials with high viscosity, high corrosiveness, etc. Good mixing effect, able to achieve uniform mixing of materials in a short period of time.
Function
Efficiently mix different materials to evenly distribute their components. Promote chemical reactions by thoroughly mixing reactants to improve reaction efficiency and quality. Improve the physical properties of materials, such as uniformity, stability, etc. Realize uniform mixing of materials with different temperatures and concentrations. In some process flows, it plays a role in dispersion, emulsification, etc., optimizing production efficiency.
Working Principle
Let the fluid flow in the pipeline and impact various types of plate components, increasing the velocity gradient of laminar flow or forming turbulence. In laminar flow, it is "segmentation position movement re convergence". In turbulent flow, in addition to the above three situations, the fluid will also generate intense vortices in the cross-sectional direction, with strong shear force acting on the fluid, further dividing and mixing the fluid, and finally mixing to form the required emulsion.
